Mackintosh Probe Test Malaysia

The probe consists of a cased screwed onto the lower end of the rod.

Mackintosh probe test malaysia. The tool consist of high yield steel rods each of length approximately 120cm that are connected each other by 25mm outer diameter couplings with a 27 9mm diameter of a 30o apex angle. This method is not able to collect any soil or rock samples and unable to report on type of soil as well. A mackintosh probe is a lightweight portable penetrometer that is designed to be a tool to investigate the soil bearing capacity. Jkr mackintosh probe test is a quick and economical way to estimate the bearing capacity of soil layer by co relating the cone penetration resistance to the bearing capacity.

Mackintosh penetration test jkr probe test the mackintosh probe development was based on the principles stated by hvorslev 1948 for drive rods for sounding and sampling and recommended methods for static and dynamic sounding by european group subcommittee 1968. 222 2 mackintosh probe testmackintosh probe test 2 2 1 carry out mackintosh or jkr probe test to depth not exceeding 15m below ground level or 400 blow per 0 30m penetration whichever achieved first. It can goes up to a maximum depth of 15 m and is recommended only for shallow foundation. 12 7 mm diameter solid rods and a 4 5 kg dead weight with standard drop height.

300 00 2 4 field density tets. Mackintosh probe test malaysia. 2 3 insitu california bearing ratio tests no 300 00 2 3 1 carry out insitu californi bearing ratio test no.
